· Unterstützt optisches und thermisches Bi-Spektrum-Bild
· Vanadiumoxid ungekühlte Focal Plane Arrays
· Thermische Auflösung 384×288
· Optische Auflösung bis zu 3072×1728@30fps
· Mindest. Beleuchtungsfarbe: 0.001Lux@F1.6
· Optischer Zoom: 44×, Digitalzoom 16×
· Smart IR, IR-Reichweite: 300m
· Eingebauter Lautsprecher
· Eingebauter automatischer Wischer
· Eingebauter elektronischer Kompass
· Unterstützt GPS/BDS
· S+265/H.265/H.264/M-JPEG
· Intelligenter Überwachungs-/Gesichtserfassungsmodus
· Laserpunkt unterstützen
· Unterstützen Sie die Klassifizierung von Mensch und Fahrzeug
· Plug-in-frei
· IP66
| Thermische Parameter | |
| Temperatursensortyp | Vanadiumoxid ungekühlte Focal Plane Arrays |
| Thermische Länge | Fest 50 mm |
| Auflösung | 384×288 |
| Piexl-Intervall | 17µm |
| Ansprechwellenbereich | 8µm~14µm |
| NETD | =40mK@f/1.0 |
| Thermisches Sichtfeld | Horizontal: 7,5°, Vertikal: 5,6° |
| Messabstand Basierend auf der Referenz: human (1,8m x 0,5m ) Fahrzeug (4m × 1,4m) | Erkennung: 4510 m (Fahrzeug), 1471 m (Mensch) |
| Erkennung: 1127 m (Fahrzeug), 368 m (Mensch) | |
| Identifikation: 564m (Fahrzeug), 184m (Mensch) | |
| Feuererkennungsentfernung Basierend auf der Referenz: Feuer (2m×2m) | 3000m |
| Hauptstrom | PAL: 25fps (384×288) |
| NTSC: 30fps (384×288) | |
| Unterstream | PAL: 25fps (384×288) NTSC: 30fps (384×288) |
| Dritter Strom | PAL: 25fps (384×288) NTSC: 30fps (384×288) |
| Kamera | |
| Bildsensor | 1/1.8″ CMOS |
| Signalsystem | PAL/NTSC |
| Mindest. Erleuchtung | Farbe: 0.001lux@ (F1.6, AGC ON), SW: 0lux mit IR |
| Verschlusszeit | 1s bis 1/100.000s |
| Tag Nacht | Dualer IR-Sperrfilter mit Auto Switch |
| Eine große dynamische Reichweite | 140dB |
| Optischer Zoom | 44× |
| Digitaler Zoom | 16× |
| Linse | |
| Brennweite | 6mm~264mm |
| Zoomgeschwindigkeit | <5s |
| Betrachtungswinkel | Horizontales Sichtfeld: 61,8° (w) ~ 2,3° (t) |
| Blendenbereich | F1.6~F5.3 |
| Pan&Tilt | |
| Schwenkbereich | 360° |
| Schwenkgeschwindigkeit | Pan Manual Speed: 0.1°~160°/s, Pan Preset Speed: 200°/s |
| Neigungsbereich | -16°~90° (Auto-Flip) |
| Neigungsgeschwindigkeit | Manuelle Neigungsgeschwindigkeit: 0,1 ° ~ 120 ° / s, voreingestellte Neigungsgeschwindigkeit: 120 ° / s |
| 3D-Position | Jawohl |
| Voreinstellungen | 500 |
| Preset Accuracy | ±0.3° |
| Scan | 8 |
| Cruise | 16, up to 32 presets per cruise |
| Pattern | 8, each with 600s memory or 1000 orders |
| Power-off Memory | Yes |
| RS-485 Protocols | DOME_PELCO_D,DOME_PELCO_P,DOME_PLUS |
| Illuminator | |
| IR LEDs | 11 |
| IR Range | Up to 300m |
| IR Irradiation Angle | Adjustable by Zoom |
| White LEDs | 2, support white/blue/red light flash |
| Compression Standard | |
| Video Compression | S+265/H.265/H.264/M-JPEG |
| Video Bit Rate | 32Kbps~16Mbps |
| Audio Compression | G.711A/G.711U/ADPCM_D/AAC_LC |
| Audio Bit Rate | 8K~48Kbps |
| Image | |
| Max. Resolution | 5.0MP (3072×1728) |
| Main Stream | PAL: 25fps (3072×1728), 50fps (2560×1440, 2304×1296, 1920×1080, 1280×720) |
| NTSC: 30fps (3072×1728), 60fps (2560×1440, 2304×1296, 1920×1080, 1280×720) | |
| Sub Stream | PAL: 25fps (704×576, 704×288, 640×360, 352×288) |
| NTSC: 30fps (704×480, 704×240, 640×360, 352×240) | |
| Third Stream | PAL: 25fps (1920×1080, 1280×720, 704×576, 640×480, 704×288, 352×288) NTSC: 30fps (1920×1080, 1280×720, 704×480, 640×480, 704×240, 352×240) |
| Image Setting | Saturation, brightness, contrast, sharpness, adjustable by client software or web browser |
| Image Enhancement | BLC/3D DNR/HLC |
| ROI | 7 Dynamic Areas for Both Main and Sub Stream |
| OSD | 16×16, 24×24,32×32, 48×48, 64×64, 96×96, 128×128, adaptable size, Letters such as Week, Date, Time, Total 5 Regions |
| Picture Overlay | Yes |
| Privacy Mask | Yes |
| Smart Defog | Yes |
| Feature | |
| Alarm Trigger | Harsh Voice Alarm, Motion Detection, Mask Alarm, Network Disable Alarm, IP Conflict, MAC Conflict Detection |
| Video Analytics (Optical) | Tripwire, Double Tripwire, Perimeter, Object Abandon, Object Lost, Loitering, Running, Heatmap, Video Abnormal, Crowd, Audio Abnormal, Demographics(People Counting), On Duty Detection, Safety Helmet Detection, Auto tracking, Face Capture, Early Warning |
| Video Analytics (Thermal) | Tripwire, Double Tripwire, Perimeter, Temperature Alarm, Fire/Smoke Detection |
| Early Warning(EW) | Yes |
| Auto-Tracking | Yes |
| Face Detection and Analytics | |
| Operating Mode | Face capture, intelligent monitoring optional, default intelligent monitoring |
| Face Detection Performance | Detects up to 32 faces at the same scene |
| Face Exposure Brightness | Default 35, 1~100 brightness optional |
| Min. Face Pixel | Default 80, 19~1920 optional |
| Precautionary Alert | Three level |
| Network | |
| Protocols | TCP/UDP/HTTP/MULTICAST/UPnP/DHCP/PPPoE/DDNS/NFS/FTP/NTP/RTP/RTSP/IPv6/SNMP/SMTP/RTMP |
| System Compatibility | ONVIF (PROFILE S/T/G), SDK, CGI, P2P |
| ANR | Auto store video in SD card when NVR disconnected, and upload video to NVR when resumed connection (Only Support Tiandy ANR NVR) |
| Remote Connection | =7 |
| Client | Easy7, EasyLive |
| Web Version | web6 |
| Interface | |
| Communication Interface | 2 RJ45 100M/1000M self adaptive Ethernet ports |
| Audio | 1/1 |
| Alarm | 8/2 |
| Speaker | Yes |
| Reset Button | Yes |
| On-board storage | Built-in Micro SD card slot, up to 256 GB |
| RS-485 | Yes |
| BNC | Yes |
| Wiper | Yes, automatic wiper |
| Electronic Compass | Yes |
| GPS/BDS | Yes |
| General | |
| Firmware Version | – |
| Web Client Language | 15 languages Simple Chinese, Traditional Chinese, English, Spanish, Korean, Italian, Turkish, Russian, Thai, French, Polish, Dutch, Hebraism, Arabic, Vietnamese |
| Operating Conditions | -40°C~70°C (IR OFF), -40°C~40°C (IR ON), 0-95%RH |
| Power Supply | AC24V±25%,DC24V±10% |
| Power Consumption | 30W(IR OFF), 66.96W(IR ON ) |
| Protection | IP66, Lightning protection, surge protection and voltage transient protection meets EN 55035:2017 |
| Heater | N/A |
| Dimensions | F445x700mm (F308x506inch) |
| Weight | 11.85kg (21.62lb) |
| Datum | Titel | Typ | Herunterladen |
|---|---|---|---|
| 2021-10-22 | TC-H358M Spec 44X-IT-A | DOWNLOAD |
